This is an original Electric Bass Lesson control knob developed by an amateur bassist to improve the operability of bass guitars with built-in preamps. It is the ultimate knob that maximizes preamp performance, allowing you to create the sound you are most satisfied with. (Design Registration No. 1765261)
Have you ever been frustrated by the fact that you perfected your sound during rehearsal, only to find that the knobs were out of position during the live performance, preventing you from performing as you expected? With this Ultimate Knob, you can instantly correct any misaligned knobs on your onboard preamp, solving the problem!
Feature 1 Improved operability with numbers and marker lines
A number is engraved on the side of the knob so that the adjustment level can be checked numerically from the performer's point of view.Also, by placing the white marker line at the number 5, we devised it so that it can be used without discomfort even when adjusting the pot with the center click of the onboard preamp.
Feature 2 Made of aluminum and lightweight
Compared to Dual/Stack products from other companies, MONTREUX Black Amite is the lightest, but it is about half the weight of other knobs.Also, as a metal Single Knob, we were able to achieve 10g or less by using aluminum materials.
*All weights are measured values.Please note that these are not guaranteed values.
Feature 3 Side screw fixing type and 4.2mm/6.3mm/8.3mm shaft hole diameter line-up for wide range compatibility
Since it is fixed with a horizontal screw, it can be installed not only on solid shafts but also on split shafts. *Sleeves may be required when installing a split shaft.
The shaft hole diameter is designed to accommodate general 4mm/6mm Dual Shaft, 6mm/8mm Dual Shaft, and 6mm Single Shaft. *Please carefully check the shaft specifications on the pot side for actual application.
Specification.
EKS6 (Single Knob) specifications
■Outer diameter 19mmΦ
■ Height 16mm
■ Shaft hole diameter 6.3mmΦ
■ Material Aluminum
Color Anodized black finish
■ Fixed side screw type (M3 standard)
■ Accessories One M3 set screw for fixing
*Hex wrench (1.5mm) is not included.
*All dimensions are nominal values.
EKD68 (Dual/Stack Knobs) Specifications
-upper part-
■Outer diameter 19mmΦ
■ Height 16mm
■ Shaft hole diameter 6.3mmΦ
-beneath-
■Outer diameter 21mmΦ
■ Height 8.5mm
■ Shaft hole diameter 8.3mmΦ
-common-
■ Material Aluminum
Color Anodized black finish
■ Fixed side screw type (M3 standard)
■ Accessories One M3 set screw for fixing
*Hex wrench (1.5mm) is not included.
*All dimensions are nominal values.
EKD46 (Dual/Stack Knobs) Specifications
-upper part-
■Outer diameter 19mmΦ
■ Height 16mm
■ Shaft hole diameter 4.2mmΦ
-beneath-
■Outer diameter 21mmΦ
■ Height 8.5mm
■ Shaft hole diameter 6.3mmΦ (nominal value)
-common-
■ Material Aluminum
Color Anodized black finish
■ Fixed side screw type (M3 standard)
■ Accessories One M3 set screw for fixing
*Hex wrench (1.5mm) is not included.
*All dimensions are nominal values.
EBL original knobs are sold at "EBL Store Mercari"
#knob #control knob #fender #musicman #bass #guitar #preamp #AGUILAR #OBP #SADOWSKY #ESP #DELANO #SONAR #Darkglass #BARTOLINI #NTCT #TCT #XTCT #SEYMOUR #DUNCAN #KENT #Moon #NOLL #EMG #BTS #BTC #onboard #on_board #onboard preamp #MONTREUX #ALLPARTS #SCUD #knob #bass preamp #basspreamp #bass_preamp #scale #number
Since this is a limited production item, we will only be able to provide it in limited quantities.
Improved operability!Now you can play perfectly.
